Design Highlights:
1. Integrated electrical cabinet design, all-in-one machine, eliminating the need for a distribution box, saving customer installation time.
2. Ease of operation: intuitive control panel and simple operating interface, no professional training required for quick operation.
3. Stable operation: advanced control algorithm and efficient heat dissipation design ensure stable performance under long-term, high-load operation, suitable for various extreme environments.
Product Features:
1. Easy installation: the frequency converter electrical cabinet integrates design, reducing installation steps.
2. Comprehensive components: including speed control knob, reverse switch, and main circuit power switch.
3. Comfortable and quiet: the carrier frequency up to 16kHz brings a quiet working environment.
4. Smooth operation: enjoy the comfortable feeling of natural wind.
5. Support for synchronous motor tuning-free: perfect control of synchronous motors without complex settings.
Function Introduction:
1. Rapid power on/off: Quick response to enhance equipment efficiency.
2. Centralized switch control: Simplifies operational flow and enables centralized management of multiple fans.
3. 485 communication function: Supports remote monitoring and data transmission for intelligent management.
4. VVC control algorithm: A new control algorithm based on permanent magnet synchronous motors that enables flawless operation.
5. Simple debugging: Pre-integrated industry parameters with high adaptability requiring minimal parameter settings.
6. High protection level: IP54 protection rating that ensures protection against harsh environments.
7. High flexibility: One machine, multiple uses, supporting control of both synchronous and asynchronous motors.
Technical Specifications:
1. Power range: For single phase 220V: FI310-2S (0.75~1.5)G
For three phase 380V: FI310-2T(0.75~1.5)G, FI310-4T(0.75~2.2)G
2. Control mode: V/F, SVC, VVC Control
3. Motor type: Supports asynchronous motor, permanent magnet synchronous motor
4. Input terminal: X1~X3 Three multi-functional digital terminal inputs.
| Debugging parameters | |||
| Step number 1 2 3 4 5 6 7 8 | Function code P0.13 P0.04 P0.05 P0.10 P0.11 P2.03 P2.04 P2.06 | Set value 1 motor determined motor determined 0 12.0kHz motor determined motor determined motor determined | Function Description Restore factory and industrial fan parameters Enter the rated frequency of the motor Please input the upper frequency limit or maximum speed of operation required for the motor If the motor needs to be reversed, it can be set to 1 in order to achieve a change in the motor direction without altering the motor wiring Carrier frequencies above 3Hz (such as when there is a high level of electromagnetic noise from a motor, which may reach around 12K) Enter the rated frequency of the motor Input motor rated speed Input rated current of motor |
Application Area:
Widely used in large factory workshops, warehouses, machine rooms, laboratories, etc., to meet various ventilation and heat dissipation as well as temperature and humidity control requirements.
