The ST100 requires a bypass soft starter's main functions are as follows:
- Effectively reduce the starting current of electric motors, which reduces the need for distribution capacity and avoids investments in power grid capacity.
- Decrease the starting stress on electric motors and load devices, consequently extending their lifespan.
- The soft stop function effectively addresses problems related to parking surges in inertia systems, which traditional starting devices are unable to do.
- Equipped with six distinctive starting modes, it is able to adapt to complex motor and load conditions and achieve perfect starting results.
- Has reliable protection functions, effectively ensuring the safety of electric motors and related production equipment.
- The application of intelligent and networked technology using motor control technology in the development of soft starters meets the higher requirements of rapidly developing power automation technology.
The ST100 requires a bypass soft starter's main features include:
- Reliable quality assurance:
- Computer simulation design.
- SMT patch production technology.
- Excellent electromagnetic compatibility performance.
- High-temperature aging and vibration testing before assembly.
- Perfect and reliable system protection functions:
- Under-voltage, overvoltage, and voltage loss protection.
- Soft starter overheat and prolonged starting time protection.
- Input phase loss, output phase loss, and three-phase unbalance protection.
- Starting over-current, running overload, and load short circuit protection.
- Maintenance functions:
- Fault self-diagnosis (short circuit, overvoltage, undervoltage, single-phase grounding, motor overload, phase loss, blockage, and intelligent programming to determine the operating status of the towing system).
- Modular combination design to quickly troubleshoot any detected problems.
- Independent intellectual property products:
- Own software copyright.
- Proprietary electric motor starting and protection technology.
- Unique detection, debugging equipment, and processes.
- Prompt and thoughtful after-sales service:
- Reliable performance and quality lay the foundation for excellent service.
- Providing excellent and complete supporting design plans.
- Timely and thoughtful use consultation.
- Continuously improving product performance based on user feedback.
We'd like to highlight the key technical specifications of our soft starter for you.
It falls under AC-53b category and is designed in two models.
It has a rated working voltage of AC380V and insulation voltage of AC660V, with a frequency rating of 50Hz.
Our product can tolerate up to 4KV of shock and has a rated short circuit current limit of 19kA (for EM-GS3-5d5~075) and 23 kA (for EM-GS3-090~600).
It is compatible with SCPD type 1 and has an IP20 casing protection rating.
For further details, please feel free to consult with us.
The ST100 requires a bypass soft starter is widely used in industries and equipment applications, such as petrochemical, power, and metallurgical sectors, ensuring smooth start-up and stoppage of equipment like pumps, fans, and compressors. The ST100 requires a bypass soft starter minimizes shock and wear, extends equipment lifespan, reduces energy consumption, and lowers maintenance costs. With its flexible control functions and energy-saving features, it has become a vital device for enhancing motor operation efficiency.
